Thông số kỹ thuật
| Electrical | |
| Frequency response | 20 – 20kHZ ± 0.1 dB |
| SNR | >110dB (A-wt) |
| THD | < 0.02% (20 – 20kHz) |
| Decoding and post processing | |
| Dolby Atmos native decoding | 15.1 |
| DTS:X native decoding | 11.1 |
| Post processing | Dolby Surround Upmixer; DTS Neural:X Upmixer |
| Loudspeaker adjust (I) | delay, polarity, large/small, crossover |
| Loudspeaker adjust (II) | PEQ |
| Loudspeaker adjust (III) | ASPEQT Room Correction System |
| Audio/video | |
| Stereo analog inputs | 2 x gold-plated RCA L/R unbalanced |
| Digital inputs | 2 x coax RCA, 2 x optical |
| Multi-channel analog outputs | 12 x balanced XLR + 4 x CAB-20 bal. XLR |
| Digital outputs | 1 x coax RCA, 1 x optical |
| Digital video inputs | 7 x HDMI 2.0b, 4k pass-thru (7 x HDCP 2.2) |
| Digital video outputs | 1 x HDMI 2.0b HDCP 2.2, 1x HDMI 1.4 |
| Control | |
| Front-panel display | 5” LCD touch-panel |
| Serial | 2 x DB9, 2-way control, 2 x USB programming ports |
| Ethernet | 1 x ethernet, web interface + TCP/IP control |
| 12v trigger and IR | 1 x 3.5mm IN, 2 x 3.5mm OUT, IR remote |
| Charging port | 2 x USB 5V, 2A |
| Physical | |
| Product dimensions | 3.5” x 17” x 15” (8.9m x 43.2cm x 38.1cm) |
| Product weight | 23 lbs (10.4 kgs) |
| Carton dimensions | 18” x 22” x 10” (45.7cm x 55.9cm x 25.4cm) |
| Carton weight | 27 lbs (12.2 kgs) |
| Finish | black satin anodization, laser-etched logo, white chassis |
