Thông số kỹ thuật
| Electrical | |
| Power output | 200W (8Ω), 400W (4Ω), both channels driven |
| THD (amplifier) | < 0.05% (200W, 8Ω), < 0.08% (400W, 4Ω) |
| Frequency response | 20 – 20kHz ± 0.15dB |
| SNR | 118dB (A-wt.) |
| Damping factor | >1000, 8Ω @ 50Hz |
| Input impedance | 20kΩ |
| THD (pre-amp output) | <0.007% (20 – 20kHz) |
| Max output (pre-amp output) | 3.5Vrms, 7Vrms (sub out) |
| Power consumption | 40W (idle), 1440W (max), 4W (standby) |
| Control | |
| Front panel display | 4.3” touch-sensitive TFT 480×272 QVGA, RGB 65k colors |
| Ethernet/RS-232 | Serial command and UDP message protocol for all parameters |
| 12V Audio Inputs/Outputs | 1 3.5mm in, 2 3.5mm out, trigger out delay adjustable 0-2 sec |
| Stereo audio input | 4 Gold-plated RCA (unbalanced) L/R pairs |
| Balanced input | 1 XLR (balanced) L/R pair |
| 2.1 audio input | 1 Gold-plated RCA (unbalanced) L/R pair plus sub in |
| 2.1 pre-amp output | 1 Gold-plated RCA (unbalanced) L/R pair plus sub out |
| Loudspeaker out | Gold-plated 60A 5-way binding posts x 2 |
| Expansion port Physical | (up to 3 inputs or outputs with expansion card option) |
| Product dimensions | 3.5” (8.89cm) x 17” (43.2cm) x 13.0” (33.0cm) |
| Rack height | 2 RU |
| Product weight | 17 lbs. (7.71kg) |
| Finish | Black satin anodized, laser-etched logo, white rear panel |
| Carton dimensions | 10” (25.4cm) x 22” (55.9cm) x 18” (45.7cm) |
