Thông số kỹ thuật
| Electrical | |
| Power output | 200W (8Ω), 300W (4Ω), any 7 channels driven |
| THD | < 0.03% (200W, 8Ω), < 0.05% (300W, 4Ω) |
| Current capability | >18A (2.2Ω) |
| Frequency response | 20 – 20kHz ± 0.1dB |
| Tim/dim distortion | <0.003% |
| SNR | 106dB (A-wt.) |
| Damping factor | 500, 8Ω @ 50Hz |
| Input sensitivity | 1W: 100mV, 200W: 1.42V |
| Input impedance | 20kΩ |
| Power consumption | 23W (idle), 1200W (max), <1W (standby) |
| Control | |
| Ethernet/RS-232 | Status and control of standby/on, channel configuration |
| 12V | Standby/on control |
| Audio Inputs/Outputs | |
| Audio in | Gold-plated RCA (unbalanced) x 7 |
| Loudspeaker out | Gold-plated 60A 5-way binding posts x 7 |
| Physical | |
| Product dimensions | 8.5” (21.6cm) x 17” (43.2cm) x 15.0” (38.1cm) |
| Rack height | 5 RU |
| Product weight | 52.2 lbs. (23.7kg) |
| Finish | Black satin anodized, laser-etched logo, white rear panel |
| Carton dimensions | 16” (40.6cm) x 22” (55.9cm) x 20” (50.8cm) |
