Thông số kỹ thuật
| Electrical | |
| Power output | 200W (4-8Ω) all channels driven 400W (4Ω), any four channels driven 320W (4-8Ω) all channels driven, bridged mono |
| THD (amplifier) | < 0.05% (200W, 8Ω), < 0.08% (400W, 4Ω) |
| Frequency response | 20 – 20kHz + 0 / -1dB |
| SNR | >112dB (A-wt.) |
| Damping factor | >1000, 8Ω @ 50Hz |
| Input impedance | 20kΩ |
| Input sensitivity | 1.45Vrms for full rated power output |
| Gain | 28.75 dB |
| Power consumption | 40W (idle), 1440W (max), 4W (standby) |
| Control | |
| Serial | 1 x RS-232 (DB-9), Full 2-way control, 1 x USB A programming port |
| Ethernet | 1 x Ethernet, Web interface & 2-way IP control via TCP/IP or UDP |
| 12V trigger | 1 x 3.5mm IN |
| Infra-red | 1 external (rear panel 3.5mm TRS input) |
| Audio Connections | |
| Analog audio inputs | 8 x Gold-plated (XLR) balanced |
| Stereo loudspeaker outputs | 4 x Phoenix contact (20 Amp) |
| Physical | |
| Product dimensions | 3.5” (8.9cm) H x 17” (43.2cm) W x 15” (38.1cm) D |
| Rack height | 2RU |
| Product weight | 31 lbs. (15.9kg) |
| Finish | Black satin anodized, laser-etched logo, white rear panel |
| Carton dimensions | 10” (25.4cm) H x 22” (55.9cm) L x 24” (61.0cm) W |
| Rack Ear Kit Compatibility | ARM-3 (optional) |
